    Reprehenderit qui in ea

    TP4056 1A Lithium Battery Charging Board Module TYPE-C USB Interface Charging Protection Combo

    Regular price Sale price $1.00
    SKU: AL-6FBF-84hr2zrc[1]
    sales volume: 9
    classification: Electronic component market , Experimental equipment/testing equipment/development tools , Battery box/holder/battery accessories
    TYPE-C USB interface 1A protected MICRO interface 1A MICRO Interface 1A MINI Interface
    Free Size
    Buy now
    • Product description
    • After sales
    • deliver goods
    • payment
    • Customer evaluation
    • SPU: AL-6FBF-84hr2zrc[1]
    • Model: 1A with Protected MICRO Interface
    • Model: 1AMICRO Interface
    • Model: 1AMINI Interface
    • Accessory Name: 1AMINI Interface
    • Accessory Name: 1AMICRO Interface
    • Accessory Name: 1A with Protected MICRO Interface



    531(2)



    TP4056 1A鋰電池充電板模塊 TYPE-C USB接口充電保護二合一





    本電路板有充電功能和電池放電保護功能 可邊充邊放電

    模塊特點及參數:
    輸入端帶有TYPE C USB
    母座

    可以直接用手機充電器來做輸入給鋰電池充電,

    並且依然保留有輸入電壓接線焊點,可以非常方便的DIY

    輸入電壓:5V

    充電截止電壓:4.2V ±1%
    最大充電電流:1000mA

    電池過放保護電壓:2.5V

    電池過流保護電流:3A

    板子尺寸:2.6*1.7CM



    使用方法:

    注意:第一次接入電池時,可能OUT+和OUT-之間無電壓輸出,這時接入5V電壓充一下電就可以激活保護電路了,電池從B+ B-上短開再接上的話也需要充一下電以激活保護電路。當使用手機充電器來做輸入時注意充電器必須要能輸出1A或以上的,不然可能會不能正常充電

    TYPE C USB母座及其旁邊的+ - 焊盤為電源輸入端,接入5V電壓。B+ 接鋰電池的正極,B-接鋰電池的負極。OUT+和OUT-接負載,比如接移動升壓板正負極或者是其它負載。

    接好電池到B+ B-,插入手機充電器到USB母座,紅燈亮為正在充電,藍燈亮為充滿。

    1A 鋰電池充電與保護一體板 充電+保護 二合一 充電模塊

    注意:充電時應斷開OUT端上的負載



    模塊特點及參數:


    輸入端帶有MICRO USB母座,可以直接用手機充電器來做輸入給鋰電池充電,

    並且依然保留有輸入電壓接線焊點,可以非常方便的DIY

    輸入電壓:5V

    充電截止電壓:4.2V ±1%
    大充電電流:1000mA

    電池過放保護電壓:2.5V

    電池過流保護電流:3A

    板子尺寸:2.6*1.7CM



    530 (3)

    530 (5)

    530 (8)

    531 (5)



    O1CN01AFVno61Lwkn0IWGim_!!2675

    O1CN01uL2WEp1LwkmxjjzbJ_!!2675

    O1CN015AcyAW1LwkmzZHisk_!!2675
